CLIP top Wide angle hinge for zero protrusion 155°, overlay application

CLIP top Wide angle hinge for zero protrusion 155°, overlay application
CLIP top Wide angle hinge for zero protrusion 155°, overlay application
Ident no: 07523966
Part no.: 71T7550 MB V125 NI
Box qty: 125 pcs

CLIP top Wide angle hinge for zero protrusion 155°, overlay application

boss fixing
expand_more
Ident no: 07523966 Part no.: 71T7550 MB V125 NI Box qty: 125 pcs
error_outline

Please log in to see prices and availability.
info Product information expand_more

Product information

The wide angle hinge with zero protrusion is suitable for cabinets with large opening angles, pull-out shelves and inner drawers. In combination with the tried-and-tested CLIP mechanism, it is very easy to assemble and adjust, permitting precise adjustment of the door.
  • 3-dimensional front adjustment (with mounting plate) for convenient adjustment and a uniform gap layout
  • Practical CLIP assembly method
  • Compatible with all CLIP mounting plates
  • With integrated spring to help the door to close and keep it closed
  • Convenient depth adjustment with spiral screw
description Technical data expand_more

Technical data

type
Wide angle hinge for zero protrusion
mounting system
CLIP
hinge system
CLIP top
opening angle
155 °
application
overlay application
