AVENTOS HS top lever

AVENTOS HS top lever
AVENTOS HS top lever
Ident no: 05705570
Part no.: 22S3501 HEBEL V12 NI
Box qty: 12 pcs

AVENTOS HS top lever
Ident no: 05705570 Part no.: 22S3501 HEBEL V12 NI Box qty: 12 pcs
error_outline

Please log in to see prices and availability.
info Product information expand_more

Product information

The lever arm secures the connection between the lift mechanism and the front fixing bracket and ensures stable motion when opening and closing the wall cabinet front.
  • Tool-free mounting on the lift mechanism thanks to the reliable CLIP assembly method
  • Removable lever arm on the lift mechanism simplifies furniture manufacturing and kitchen assembly, as none of the parts protrude
description Technical data expand_more

Technical data

type
lever
suitable for lift system type
HS top
lever type
22S350x
min. front height
318.00 mm
max. front height
800.00 mm
